● Air sound insulation: STC58

● Power supply: 380 volts

● Weight: 36.5 kilograms per square meter

● Speed: 1.5 meters to 3 meters per minute

● Thickness of soundproof wall: 300mm

● Maximum panel length: 3660 millimeters

● Ceiling opening: 1430mm -1570mm

● Collection space height: 1/5-1/10 of the ceiling height

● There are no restrictions on decorative materials on the surface of the panel, which can be sprayed, wood veneer, wallpaper, wall cloth, etc. The thickness of the decorative surface cannot exceed 3mm

Flexible, Silent, Durable & Customizable

Hzfold Vertical Folding Partition:

● One-key Operation: Effortless, quiet, and no manual labor required

●Space-saving Storage: Panels fold vertically into the ceiling, freeing up floor space

●Sleek Design: No unsightly side storage pockets needed ●Customizable: Tailor-made to fit your space and style

Core Advantages

● Safety is our top priority, with these key protections: Dual Key Switch Control: Two series-wired spring-return keyswitches require simultaneous, continuous pressure to operate. The wall stops instantly when pressure is released (no coasting)

● Flexible Operation: Partial opening/closing, pausing, and reversingare all supported

● Heavy-Duty Gear Motor: Industrial-grade sealed motor handleshundreds of starts/stops per hour, ensuring long-term reliability.

● Hydraulic Anti-fall Device: Automatically brakes if the wall's speedexceeds normal levels, limiting descent to max150% of standard speed

Safety Features
